Product Description

• Digital Distribution:1 HDMI Source to 4 HDMI displays
• Resolution Support:SD, HD, and VESA up to UHD/4K (4096×2160/60/30/24 or 3840×2160/60/30/24)
• Ultra HD/4K:Suppports Ultra HD/4K Signal transmission
• 3D Ready:Capability to pass 3D stereoscopic signal formats
• Auto Sensing:Auto Sensing and formatting for connected HDMI devices
• EDID:Internal library with 16 default EDID configurations for each input, including native EDID data for any Output/Display
• EDID Control™:Default EDID for 1080i or 1080p systems
• Full Buffer System:Manages TMDS re-clocking/signal re-generation, HDCP source Á display authentication, Hote Plug Management and EDID Control handshake
• Lossless Compressed Digital Audio:Dolby® TrueHD, Dolby® Digital Plus and DTS-HD Master  Audio™
• Deep Color Support:Up to 12bits/color (up to 18 bits/color@4K/60)
• I2C Communications:EDID and HDCP transparency from Display to Source
• Control:Front panel push button and LEDs, Optical IR
• Licensing:DFully licensed and compatible with HDMI up to UHD 4K/60Fps nd HDCP 1.0 to 1.4 technologies.  For HDCP 2.2 sources use KD-HDFIX22 in conjunction with this product
• Major Control System Support:Compass Control®, AMX®, Control4®, Crestron®, KNX®, RTI®, Savant, URC®, Honeywell®, HAI®, Leviton®, etc.

Specs

HDMI In	Yes
HDMI Out	Yes
Number of HDMI Inputs	1
Number of HDMI Outputs	4
Input Voltage	5 V DC
Color	Black
Material	Plastic
Height	1.2″
Width	8″
Depth	3.1″
Weight (Approximate)	12.80 oz
Certifications & Standards	CE
Environmentally Friendly	Yes
Environmental Certification	RoHS WEEE
Package Weight	1.45 lb
