Product Highlights:
The SFP ports enable network uplinks of up to 1 Gbps
PoE support simplifies your network infrastructure and cabling.
The PoE ports offer 802.3af/at to power your PoE devices, such as UniFi apps and cameras
The 1.3″ touchscreen displays status information for easy monitoring and quick troubleshooting
Ports 1-32: POE+ IEEE 802.3af/at (Pins 1, 2+; 3, 6-)
Mechanical
Dimensions 442.4 x 285 x 43.7 mm (17.4 x 11.2 x 1.7″)
Weight Without mounting brackets: 3.9 kg (8.6 lb)
With mounting brackets: 4 kg (8.8 lb)
Enclosure material SGCC steel
Hardware
Management interface Ethernet In-Band
Networking interface (48) GbE RJ45 ports
(4) 1G SFP Ethernet ports
Total non-blocking throughput 52 Gbps
Forwarding rate 77.376 Mpps
Power method Universal input, 100—240V AC, 50/60 Hz
Power supply AC/DC, internal, 60W
Supported voltage range 100—240V AC
Max. power consumption 40W
ESD/EMP protection Air: ± 16kV, contact: ± 12kV
Operating temperature -15 to 40° C (5 to 104° F)
Operating humidity 10 to 90% noncondensing
Certifications CE, FCC, IC
LEDs
System Status
Ethernet Speed/link/activity
SFP Link/activity
