Product Highlights:
The NEC P502WL-2 is the smallest footprint 5000 lumen installation projector with a laser/phosphor light source that makes it ideal for higher education classrooms, corporate boardrooms and government training rooms. With more consistent brightness, improved color fidelity, and tilt-free or portrait modes these projectors will deliver in new verticals such as retail, simulation, and theme park installations. Furthermore, the laser module delivers 20,000 hours of virtually maintenance-free operations, reducing your total cost of ownership!
Advanced video processing from Texas Instruments delivers exceptional picture management control for both progressive and interlaced sources, while making images more vibrant, colors more realistic and blacks richer with detail.
Provides unified management, including the ability to switch the power on and off for multiple projectors connected to a network.
Protects the lamp when the projector is accidentally unplugged or the power strip is switched off. Enables the fan to continue running until the lamp is properly cooled down. Internal sensors monitor lamp temperature and prevent the lamp from powering on.
High contrast images from the latest Texas Instruments DLP engine featuring BrilliantColor™ technology with improved color accuracy
Presets provide for adaptive color tone correction to display properly on non-white surfaces.
Calculates the positive effects of operating the projector in ECO Mode, which is encouraged by an optional message at startup. A green ECO Mode button on the remote control makes the switch easy.
Ensure quick switching between presentations and allows for simultaneous digital connections of high-definition sources
Lens shift saves time and simplies installations by adding flexibilty to your projector placement.
Enables projector to automatically turn off when an incoming signal is not detected from any of the inputs.
Integrated RJ45 connection for quick connection to the LAN (10/100 base-T capability).
Ensures detailed images when non-native resolution sources are connected to the projector.
Powers on the projector when a computer signal is detected.
Extends light source life, lowers audible noise and reduces total cost of ownership.
For use in applications up to and including 24×7 operation.
Allows the projector to be rotated freely (360°) in order to point up or down depending on the installation requirements.
Permits playback (without a PC) of presentations or display images stored as JPG files from a USB flash drive.
Adjusts the volume of an external speaker system using the projector’s remote control.
Allows you to transmit images from a PC wirelessly to the projector, eliminating the need for traditional cumbersome cables.
Powerful 20-watt speaker provides volume needed for large rooms
Intuitively syncs the projector with most computer signals and features one-touch image optimization.
Enables decoding and display of text information from a video.
provides wired and wireless data transmission via peer-to-peer or over the network
Allows for distortion-free display of content in various orientations, creating new application opportunities.
Ability to install a projector in its side to create a 10:16 portrait image
Enables the user to monitor and make adjustments to the projector from a remote location.
Used to control the projector directly from a computer without the need for a physical remote.
Allows users to send an image from an iPad directly to the projector
Aspect Ratio | 16×10 | Screen Resolution | WXGA 1280×800 |
Maximum Resolution | WUXGA 1920 x 1200 | Contrast Ratio (typical) | 15,000:1 with auto iris |
Horizontal (Analog/Digital) | 15-100 kHz | Vertical | 50-120 Hz |
Supported Video Standards | NTSC, NTSC4.43, PAL, PAL-60, PAL-M, PAL-N, SECAM | SD/HD Video Signal Compatibility | 480i, 480p, 576i, 576p, 720p, 1080i, 1080p |
PC Signal Compatibility | VGA, SVGA, XGA, SXGA, SXGA+, UXGA, WUXGA | Macintosh Signal Compatibility | Yes |
Sync Compatibility | Separate Sync / Composite Sync / Sync on G | External Control | RS-232, IR, DDC/CI, USB |
Input Terminals
RGB1(analog):
VGA 15-pin D-sub
RGB2(digital):
HDMI w/HDCP
RGB3(digital):
HDMI w/HDCP
RGB5(digital):
HDBaseT
Video 1:
RCA
|
Output Terminals
Audio Out:
1/8 in. stereo (Variable audio out)
|
On | 530W / 420W / 6W / 0.5W | Input Current | 6.8-2.5A |
Power Requirements | 100-240V AC, 50/60 Hz |
Dimensions (WxHxD)
Product:
18.5 x 14.4 x 5.4 in. / 469 x 365 x 137mm
|
Weight
Net Weight:
19.4 lbs. / 8.8 kg
|
Operating Temperature | 41-104°F / 5-40°C | Storage | 14-122°F / -10-50°C |
Registered owners receive a 5-year or 20,000 hours parts and labor warranty including InstaCare next business day exchange. |
|
Display Technology | DLP (0.66″ DMD) | Lamp Type | Laser/Phosphor |
Light Output(Lumens) | 5000 normal | Light Source Life | 20,000 hours |
Screen Size (diagonal) | 30 to 300 in. / 0.76 to 7.6m | Throw Ratio | 1.3-2.2:1 |
Projection Distance | 2.6 to 46.6 ft. / 0.8 to 14.2m | Projector Angle | 12.6 to 12.9° tele / 21.0 to 21.9° wide |
Lens
Zoom:
1 to 1.7
Focus:
Manual
F number, fnumber:
F=2.0, f=18.2 to 31.1mm
|
Keystone Correction | +/- 25° horizontal, +/- 30° vertical |
Installation Orientation | Floor/Front, Floor/Rear, Ceiling/Front, Ceiling/Rear | Fan Noise | 39 dB normal / 33 dB eco |
Regulations | USA UL 1950 FCC Class B, Canada CSA 950 (C-UL), NOM |
