Product Description

Features

• COB Technology (Chip On Board) produces powerful, smooth RGB color mixing with rich palettes of color and no color shadows
• Smooth RGB Color Mixing (fast or slow color change operation)
• Great for Stage Lighting, Bands, Night Clubs & Mobile Entertainers
• Emits less heat on performers on stage as opposed to conventional stage lighting
• RF Remote Control control up to 25 meters
• Refresh Rate: 3.6KHz

Specs

Specifications

Source
Light Source: Each fixture has 1x 30-Watt TRI Color COB LEDs
LUX @ 3M: 1345
Long Life LEDs (Rated at approximately 50,000 hrs.)
Beam angle: 90-degree

Control
Digital DMX Display with 4-button menu for easy navigation
4 Operational modes: Sound Active, Auto Run, Built-In Programs, & DMX-512
Stand Alone or Primary/Secondary Configuration
Pixel Flip option changes pixel orientation
14 Built-in Programs
5 DMX Channel modes: 3, 5, 9, 12 and 18 channels
Strobe & Pulse LED Effect
Electronic Dimming: 0-100%
5 selectable Dim Curves (Standard, Stage, TV, Architectural & Theatre)
Foot Controller Features: Mode, Black Out and Program Change
With Wired Digital Communication Network

Connections
3-Pin DMX In/Out
IEC In and IEC out to daisy chain power
2x power plugs on rear to plug in other lighting fixtures (120V = Edison, 230V = Shuko)
5-pin DMX In to connect the foot controller

Electrical
Multi-voltage operation: AC 100V-240V 50/60Hz (IEC Input)
Power Draw: 144W Max (entire system)
