Product Highlights:
The Coemar LEDko FullSpectrum is a modular 120 W multi-LED light engine designed for profile-style fixtures, delivering a uniform, flat field beam with smooth, pixel-free color mixing. By combining multiple colored LEDs, it can produce saturated colors as well as tunable whites from 3000K to 9000K for stage, studio, and architectural applications where consistent color and clean shadows matter.
The award winning colormixing system supports full spectrum color plus a wide range of whites (3200 K to 9000 K), with built-in digital color filters for repeatable looks. Color calibration helps maintain consistency between fixtures, which is especially useful when matching units across an installation or inventory.
Designed for a smooth, even output, the LEDko FullSpectrum produces a uniform light beam with no pixels, dots, or multicolor shadows. It is also compatible with Fresnel and PC optics with shutters (Soft Profile), supporting different beam and shaping needs depending on your setup.
Control is via bi-directional DMX 512 with 5-pin XLR in/out, selectable channel modes (1, 4, 8, or 12), and an option to switch the LED display off via DMX. Electronic 16-bit dimming with two curves (simulating halogen or discharge lamp based fixtures) allows smoother fades and more familiar on-stage behavior. Guaranteed flicker-free operation (DMX controlled PWM frequency) makes it suitable for camera work where flicker can be a concern.
PowerCon In/Out supports daisy-chaining, powering up to 16 fixtures in series for simplified installation. With an LED life rated at 50,000 hours at 70% lumen intensity maintenance and no maintenance required, it is a practical choice for venues that need dependable output with minimal service time.
Key Features
● Red, Green, Blue, Cyan, Lime, Amber light source, 20 bit
color mixing
● Color mixing with hue and saturation control
● Green-Magenta adjustment
● High CRI> 95
● CCT from 2.700 K to 10.000 K (through DMX Chart) or up to
20.000 K (through Display)
● High lumen flux and flat field
● Swappable lens tubes between 5°–90°
● Soft profiling thanks to Fresnel and PC optics (Coemar patent)
● Four blade framing system, each shutter blade is adjustable
for radial position and angle
● Flame-retardant technopolymer reinforced with fiberglass
● Custom color on request (optional)
● Manual (standard) or Pole Operated Pan-Tilt (optional)
LED Source
● CCT Range
● Color Rendition Average
● Luminous flux
● Green-Magenta adjustment
● Dimming
● Dimming Smooth Selection
● Strobe
● Available Optics
● Camera flicker control/Hz range
● Calibrated Cob
● L80 Rating
(hours to 80% output)
● Pattern projection
● Pattern size
RGBCLA COB LED (Red, Green, Blue, Cyan, Lime, Amber) – Color mixing with hue and saturation control
● ● ● ● ● 2.700 K → 20.000 K
CRI > 95, TLCI > 95
Lens Tube 14°: 5.644 lm (3.200 K), 6.476 lm (5.600 K)
Lens Tube 19°: 4.391 lm (3.200 K), 4.928 lm (5.600 K)
Lens Tube 26°: 4.654 lm (3.200 K), 5.429 lm (5.600 K)
Lens Tube 36°: 4.668 lm (3.200 K), 5.981 lm (5.600 K)
Lens Tube 50°: 5.714 lm (3.200 K), 6.707 lm (5.600 K)
Continously adjustable from full minus-green to full plus-green
8 or 16 bit, 5 selectable curves: Exponential, Logarithmic, Linear, Halo and Standard
Fast, Slow and Very Slow
Electronic strobe, synchronized, random, pulse effect
Swappable lens tubes between 5°–90°
Yes: 20.000 Hz
Yes
50.000 Hours
Yes
A or B
● Voltage Input
● Power Consumption
● Power Connection
● Data Connection
● Ambient Operating Temperature
● Fan (controllable)
80-264 V, 50-60 Hz, Auto-sensing
220 W Maximum – 1.06 A at 230 V, 2.13 A at 115 V – cosφ: 0.9
In and Out PowerCON TRUE1 Top connectors, 1.5 m (4.9 ft) PowerCon cable without power plug
In and Out DMX 5 pin locking XLR connectors
-10°C ~ +40°C (14°F ~ 104°F)
Yes, 4 different settings: Silent, Studio, Auto, DMX regulated
● Protocols
● RDM configuration
● DMX Channels
● Display
● Software upload
● Yoke
● Materials
● Framing System
● Weight
● Weight with Front Barrel
● Length
● Height
● Width
● IP Rating
● Color options
DMX-512, RDM (Remote Device Management), Wireless (optional by LumenRadio)
Yes
16 / 7 / 1 / Studio / RGB / Fine RGB / Sunrise Mode
Graphic OLED with on-board selector for quick setting
Through DMX input (With RDM inteface code AC10011A001)
Manual (standard) or Pole Operated Pan-Tilt (optional)
Flame-retardant technopolymer reinforced with fiberglass
Four stainless steel shutter blades in a two-plane assembly, 0.40mm (AISI 316)
Body: 6 Kg/13.2 lbs – With 28°-40° Optic: 8.5 Kg/18.7 lbs
7.2 Kg/ 15.9 lbs
Body: 362 mm/14.2 in – With 28°-40° Optic: 601 mm/14.2 in
189 mm/7.4 in – With bracket: 372 mm/14.6 in
355 mm / 13.97 in
IP20 (available IP65 LEDko Ext Series)
Black (standard), custom color on request (optional)
GKIT17 (USA) / GKIT16 (EU)
BC10011A106
1.5 m power cable with PowerCON TRUE1 Top and bare ends
Metal Gobo Holder
NOTE: 5 PIN DMX
